Compare SolarEdge Solar Panels & Inverters

SolarEdge

Since being established in 2006, SolarEdge has become a world leader in developing smart solar technology.

They offer a range of solar products including a smart PV module which has been designed for simple installation and works alongside their industry leading inverters.

Their innovative DC-optimised solar inverter has improved energy harvesting and management from solar PV systems to deliver increased generation and lower costs so you can see a return on your solar investment sooner.



Get Free Solar Panel Quotes:        Get quotes and compare prices.



SolarEdge Smart Module

Smart modules from SolarEdge are a complete solar solution that are fitted with power optimisers to maximise energy generation.

  • Fitted with a pre-assembled power optimiser to reduce installation time
  • Fully-optimised energy output as the generation of each module is tracked individually
  • Visibility of performance
  • Comes with a 15 year product warranty and 25 year performance warranty
  • Designed to work alongside SolarEdge inverters
SolarEdge 60-Cell Monocrystalline PERC Module
Model SPV300-60MMJ SPV305-60MMJ SPV310-60MMJ
Module Power 300 W 305 W 310 W
Module Efficiency 18.3% 18.6% 18.9%
Number of cells 60 (6 x 10)
Dimensions (LxWxH) 1,650 x 992 x 40
Weight 18.8 kg
Operating Temperature Range -40°C to 85°C
Product Warranty 15 years

Combining a smart module with a SolarEdge DC inverter delivers greater output from each module.

Single Phase Inverter with HD-Wave Technology

The single phase inverter with HD-Wave Technology has seen SolarEdge really push on from traditional solar inverter technology. With a range of models in this inverter range of 2.2 kW up to 6 kW they can suit a variety of solar PV systems.

A fixed string voltage helps to maintain efficiency at the highest level all of the time, no matter the string length or temperature.

SolarEdge’s single-phase inverter can also manage battery and system energy when part of the complete StorEdge system.

This solar inverter has even picked up several awards, including the Intersolar Award 2016 and 2018 Edison Award.

  • Record breaking efficiency of 99%
  • Can be commissioned from a smartphone using the SolarEdge SetApp
  • Low heat dissipation helps to increase reliability
  • Oversizing of up to 155%
  • Advanced safety features
  • Integrated arc fault protection increases safety
  • Suitable for indoor and outdoor installation
  • Comes with a 12 year warranty that can be extended to 20-25 years
SolarEdge Single Phase Inverter with HD-Wave Technology
Model SE2200H SE3000H SE3500H SE3680H SE4000H SE5000H SE6000H
Max DC Power 3,400 W 4,650 W 5,425 W 5,700 W 6,200 W 7,750 W 9,300 W
Rated AC Power Output 2,200 VA 3,000 VA 3,500 VA 3,680 VA 4,000 VA 5,000 VA 6,000 VA
Maximum Inverter Efficiency 99.2%
Dimensions (HxWxD) 280 x 370 x 142 mm
Weight 7.8 kg 9 kg 10.6 kg
Operating Temperature Range -40°C to 60°C
Installation Indoor or outdoor
Warranty 12-25 years

Single Phase Inverter with Compact Technology

This single-phase DC-optimised solar inverter is ideal for smaller solar systems (4-8 modules) . By adding a SolarEDge inverter to your solar PV system, it will help to increase generation and give you more visibility of performance.

To increase generation from each solar module, the inverters are fitted with Maximum Power Point Trackers (MPPTs) and can be fitted with either 1 or 2 60-cell PV modules or a single 72 to 96-cell module.

  • Includes a power optimiser and inverter that are designed to work together
  • Lightweight and compact to help make installation more straightforward
  • SafeDC is a safety feature which reduces system voltage to 10V
  • Can be installed indoors or outdoors
SolarEdge Single Phase Inverter with Compact Technology
Model SE1000M SE1500M SE2000M
Max DC Power 1,350 W 2,025 W 2,640 W
Max AC Power Output 1,000 VA 1,500 VA 2,000 VA
Maximum Inverter Efficiency 97%
Dimensions (HxWxD) 340 x 239 x 127 mm
Weight 6 kg
Operating Temperature Range -40°C to 60°C
Installation Indoor or outdoor
Warranty 12-25 years

SolarEdge monitoring

With SolarEdge monitoring you’ll be in a position where you can keep an eye on the performance of your solar PV system. The immediate fault detection with deliver alerts when there’s an issue.

  • Visual representation of solar PV production and energy consumption
  • Schedule performance reports and export them
  • Accessible from a desktop, smartphone or tablet
  • Share on social to generate referrals

How much do SolarEdge solar inverters cost?

The Single Phase Inverter with HD-Wave Technology range is more advanced and likely to cost between £510 – £1,100, depending on the model. They are likely to be more costly than the SolarEdge inverters with compact technology which tend to sit around the £400 – £510 mark.
